Compatible with mainstream NVR devices such as Haikang and Dahua
Technical Specifications
| SoC | AK3918E V300S |
| Sensor | 2.0M CMOS |
| Lens | 3.6mm Megapixel Lens |
| Nightvision | 8LEDs |
| Signal to Noise ratio | ≥50dB（AGC OFF） |
| Nightvision | Auto control IR Cut Filter |
| Gain Control | Auto |
| White Balance | Auto |
| Exposure | Program mode (customizable shutter interval), shutter mode (1/5 - 1 / 20,000s), support slow shutter |
| Compression | H.264 Main profile |
| Audio | G711, PCM 1 input: linear, impedance 1KΩ, 1 output, linear, impedance of 600 Mic optional |
| Max Resolution | 1920x1080 @ 15fps |
| Video Resolution | Main stream: 1920x1080, 1280x960, 1280×720 |
Video Resolution Output Bitrate | Sub Stream: 640×480, 480x360, 352×288, 320×240, 176×144 |
| Fixed bit stream (CBR) or variable bit rate (VBR), the code can be set range: 32Kbps ~ 10Mbps | |
| Network Protocol | TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P |
| ONVIF | ONVIF2.4 |
| Mobile | Android / iOS apps |
| Network | 2. 4G WIFI 802.11b/g/n |
| Power | 12VDC / 802.3af PoE |
| Working Temperature | -20°C ~60°C |
| Working Humidity | 0%-90% RH (no condensation) |
| Color box size |
