Highlight Features
Key Specification
Dimensions (Diameter x Length, including mounting kit) : 368.5 x 271 mm(14.5 x 10.7 in.)
Working Distance : 15 km
Gain : 23 dBi
Angle : H: 9°, V: 9°
Capacity : 5 GHz, 867 Mbps
Port : 1 x 10/100/1000 Mbps
IP Rating : IP65
Operation Temperature : * –40℃ to +70℃ (–40°F to +158°F)
ESD±24 kV Contact/ Air
Surge Protection 6 kV
Power 24 V Passive PoE
LED 3 Signal Strength LED 1 LAN LED 1 System LED
Pairing Method One-touch pairing in 30 sec App pairing in 2 mins
